2X2 PANEL + EMERGENCY BATTERY BACKUP (VARIABLE CCT) | 25-30-35W 4550 LUMENS | DIMMABLE | 120-347V
SKU: PL22-VAR-V5-EM
This 2'x2' tunable back-lit LED slim panel has a built-in 15W emergency driver which can provide up to 90 minutes of power (to the panel) during emergencies/ power outages. It offers power (25W, 30W, 35W) and CCT options (3500K, 4000K, 5000K) to brighten your space. Use it in residential or commercial areas for long-term quality performance and safety you need to respond to those unforeseen emergencies.
Performance Data
Indoor/Outdoor: Indoor Indoor
Minimum Operating Temperature: -4 °F -20 ℃
Input Voltage: 100-347Vac 100-347Vac
Beam Spread: 110 ° 110 °
Efficacy: 130 lumens/Watt 130 lumens/Watt
Battery Power: 15 W 15 W
Rated Power(W): 25W | 30W | 35W 25W | 30W | 35W
Colour Temperature: 3500K | 4000K | 5000K 3500K | 4000K | 5000K
Maximum Operating Temperature: 104 °F 40 ℃
Maximum Lumens: 4550 lm 4550 lm
Equivalent to: 64W 64W
CRI (Colour Rendering Index): 80+ 80+
Battery Life: 90 Minutes 90 Minutes
Suitable Conditions: Damp Damp
IP Rating: IP40 IP40
Compatible with: Mounting Kits Mounting Kits
Integrated Battery: Yes Yes
Physical Data
Knockout sizes: 1/2 in 1.27 cm
Junction Box Length: 7 7/8 in 20 cm
Junction Box Height: 1 5/16 in 3.3 cm
Height: 1 5/16 in 3.3 cm
Number of knockouts/Inlets: 6 6
Width: 23 3/4 in 60.3 cm
Length: 23 3/4 in 60.3 cm
Junction Box Width: 3 1/8 in 8 cm
Body material: Aluminum and Iron Aluminum and Iron
Ordering Info
Size: 2'x2' 2'x2'
Warranty: 5 Year(s) 5 Year(s)
Product Lifetime: 50000 Hours 50000 Hours
Certifications: cETLus cETLus
DLC Approval: DLC Premium DLC Premium
Ordering Code: PL22-VAR-V5-EM PL22-VAR-V5-EM
Application: Residential and Commercial Residential and Commercial
Product DLC Code: S-9CN7M6 (Low-Bay Luminaires for Commercial and Industrial Buildings) | S-OY48RM (2x2 Luminaires for Ambient Lighting of Interior Commercial Spaces) S-9CN7M6 (Low-Bay Luminaires for Commercial and Industrial Buildings) | S-OY48RM (2x2 Luminaires for Ambient Lighting of Interior Commercial Spaces)
Product Colour: White White
Series: With emergency driver With emergency driver
