6" DOWN LIGHT | CCT & WATT. VAR. | 10-13-18-21-24W | 2500 MAX LUMENS | 0-10V | 120-347V | V1
SKU: CDL6-10W-24W-VAR-WH-V1
The 6" commercial downlight provides reliable lighting for offices, retail stores, hotels, and bathrooms. It has selectable power (10W, 13W, 18W, 21W, 24W) and selectable color temperatures: 2700K, 3000K, 3500K, 4000K, and 5000K. It supports 0-10V and ELV dimming for flexible control.
This downlight is rated for wet areas, airtight, and IC-rated for direct insulation contact. It comes with a 30" BX cable and a 1/2" connector for quick setup. The high CRI (>90) ensures clear and natural colors. The 95° beam angle covers a wide area. With certifications like cETLus, and FCC, it lasts over 50,000 hours.
Related Products
ENERGY STAR® Certified 4-Inch Commercial Downlight | CCT & Wattage Selectable | 6W-12W | 1200 Lumens Max | 0-10V Dimmable | 120-
ENERGY STAR® Certified 8-Inch Commercial Downlight | CCT & Wattage Selectable | 10W-25W | 2500 Lumens Max | 0-10V Dimmable | 120
Ordering Info
Size: 6" 6"
Product Colour: White White
Application: Commercial Commercial
Product Lifetime: 50000 Hours 50000 Hours
Ratings and approvals: Air Tight Air Tight
Warranty: 5 Year(s) 5 Year(s)
Certifications: cETLus cETLus
Ratings and approvals: FCC | IC Rated FCC | IC Rated
Ordering Code: CDL6-10W-24W-VAR-WH-V1 CDL6-10W-24W-VAR-WH-V1
Performance Data
Nominal Input Current: 198mA A 198mA A
Suitable Conditions: Wet Wet
Maximum Operating Temperature: 104 °F 40 ℃
Minimum Operating Temperature: -13 °F -25 ℃
CRI (Colour Rendering Index): 90+ 90+
Beam Spread: 95 ° 95 °
IP Rating: IP54 IP54
Efficacy: ≥114 lumens/Watt ≥114 lumens/Watt
Indoor/Outdoor: Indoor Indoor
Colour Temperature: 2700k | 3000k | 3500k | 4000k | 5000k 2700k | 3000k | 3500k | 4000k | 5000k
Rated Power(W): 13W | 18.5W | 21W | 24W | 9,5W 13W | 18.5W | 21W | 24W | 9,5W
Maximum Lumens: 2750 lm 2750 lm
Input Voltage: 120–347Vac 120–347Vac
Physical Data
Body material: Aluminum | Polycarbonate | Steel Aluminum | Polycarbonate | Steel
Height: 4-1/16 in 10.4 cm
Cutout Opening Size: 6-1/8 in 15.5 cm
Power cord length: 26 in 66 cm
Mounting Type: Recessed Recessed
Diameter: 8-7/16 in 21.4 cm
